MasterTrack 588
The MasterTrack 588® from Brannstrom is an advanced Bilge Discharge Monitoring and Control System designed to ensure compliance with international marine environmental regulations by continuously monitoring, recording, and controlling bilge water discharge operations. Acting as a secure onboard environmental compliance management system, it provides complete traceability of discharge activities while preventing unauthorized overboard discharge.
Description
Built around the proven BilgMon 488® 15 ppm Bilge Alarm technology, the MasterTrack 588® records critical operational data including oil content, discharge volumes, overboard valve status, vessel location, and system access events. Its tamper-proof black-box recording functionality provides vessel operators, inspectors, and authorities with reliable documentation of all discharge operations.
Specifications
- Equipment: Bilge Discharge Monitoring and Control System
- Manufacturer: Brannstrom
- Model: MasterTrack 588®
- Application: Bilge Water Monitoring & Discharge Control
- Oil Content Limit: ≤15 ppm
- Alarm System: Integrated BilgMon 488®
- Data Storage: Automatic Logging Every 10 Minutes
- Data Access: USB Interface & Optional Printer
- Security: Tamper-Proof Black Box Recording
- Installation: Marine Environmental Compliance Systems
Technical specification
| Parameter | Specification |
|---|---|
| System Type | Bilge Discharge Monitoring & Control System |
| Model | MasterTrack 588® |
| Oil Content Monitoring | Continuous Monitoring |
| Discharge Limit | ≤15 ppm |
| Integrated Alarm System | BilgMon 488® 15 ppm Bilge Alarm |
| Data Logging Interval | Every 10 Minutes |
| Discharge Volume Recording | Yes |
| Oil Content Recording | Yes |
| System Status Recording | Yes |
| Overboard Valve Status Recording | Yes |
| System Door Status Recording | Yes |
| GPS Integration | Optional |
| Position Logging | Vessel Position During Discharge |
| Data Retrieval | USB Interface |
| Printout Capability | Optional |
| Security System | Tamper-Proof Black Box Function |
| Cabinet Security | Locked Cabinet with High-Security Key Access |
| Supplied Keys | 3 Security Keys |
| Automatic Discharge Prevention | Yes |
| Overboard Valve Control Integration | Yes |
| Rejected Water Recording | Yes |
Applications
- Cargo Vessels
- Bulk Carriers
- Container Ships
- Oil & Chemical Tankers
- Offshore Support Vessels
- Passenger Ferries
- Cruise Ships
- Naval Vessels
- Offshore Platforms
- FPSO Facilities
- Engine Room Bilge Systems
- Environmental Compliance Monitoring
Features
- Continuous oil content monitoring
- Integrated BilgMon 488® 15 ppm bilge alarm
- Automatic discharge limit control
- Records discharge volume and oil content
- Logs system operating status
- Records overboard valve (OBV) activity
- Monitors cabinet door access events
- Optional GPS position recording
- Automatic data storage every 10 minutes
- Tamper-proof black box recording system
- USB data extraction capability
- Optional onboard report printing
- High-security locked cabinet
- Automatic discharge shutdown when limits are exceeded
- Records total discharge and rejected water volumes
Benefits
- Ensures compliance with IMO and MARPOL environmental requirements
- Prevents illegal overboard discharge operations
- Provides complete audit trail of bilge discharge activities
- Supports PSC, flag state, and class inspections
- Protects vessel operators from compliance disputes
- Improves environmental accountability
- Reduces risk of pollution incidents
- Secure tamper-proof data storage
- Simplifies environmental reporting and verification
- Enhances operational transparency and regulatory compliance
Recorded parameters
Environmental Monitoring Data
- Oil Content Concentration
- Bilge Water Discharge Volume
- Rejected Water Volume
- Discharge Time and Date
- System Operating Status
System Security Data
- Overboard Valve (OBV) Status
- Cabinet Door Status
- User Access Events
- Alarm Events
- System Fault Events
Optional Navigation Data
- GPS Position During Discharge
- Vessel Location History
- Position-Based Discharge Records
System Components
- MasterTrack 588® Control Unit
- BilgMon 488® Bilge Alarm Integration
- Data Recording Module
- Secure Black Box Memory
- USB Data Interface
- Optional Printer Interface
- Overboard Valve Control Interface
- GPS Integration Module (Optional)
- Locked Security Cabinet
- Alarm & Monitoring System
