LSH-SXN Series
The Speed Dome Camera Series from Arges Marine is a high-speed PTZ surveillance solution designed for marine, offshore, industrial, and hazardous-area applications. Certified to ATEX, IECEx, and KCs standards for Zone 1 and Zone 2 environments, the system delivers reliable real-time monitoring, target tracking, and situational awareness in demanding operating conditions.
Description
Featuring a 2MP high-definition imaging system, 20x optical zoom, and 380°/sec high-speed pan/tilt operation, the Speed Dome Camera Series provides clear visual coverage for navigation support, vessel security, offshore monitoring, and industrial surveillance. Its compact IP68-rated marine-grade enclosure ensures dependable operation in harsh weather and corrosive environments.
Specifications
- Equipment: Marine PTZ Camera System
- Manufacturer: Arges Marine
- Model: Speed Dome Camera Series
- Camera Resolution: 2 Megapixel (2MP)
- Certification: ATEX / IECEx / KCs
- Hazardous Area Classification: Zone 1 & Zone 2
- Optical Zoom: 20x
- Pan/Tilt Speed: Up to 380°/sec
- Protection Rating: IP68
- Applications: Marine, Offshore, Industrial & Hazardous Areas
Technical specification
| Parameter | Specification |
|---|---|
| Camera Type | PTZ Speed Dome Camera |
| Resolution | 2MP High-Definition |
| Optical Zoom | 20x |
| Pan/Tilt Speed | Up to 380°/sec |
| Camera Control | PTZ (Pan-Tilt-Zoom) |
| Certification | ATEX / IECEx / KCs |
| Hazardous Area Rating | Zone 1 & Zone 2 |
| Protection Rating | IP68 |
| Housing Design | Compact Marine-Grade Construction |
| Environmental Suitability | Marine, Offshore & Industrial |
| Operation | Continuous 24/7 Monitoring |
| Weather Resistance | Extreme Weather Operation |
Available configurations
Dual ptz camera
Dual-camera arrangement providing enhanced monitoring coverage and improved situational awareness for critical operations.
Speed dome camera
High-speed PTZ camera designed for rapid target tracking and wide-area surveillance.
Zoom bullet camera
Long-range surveillance camera equipped with optical zoom for detailed monitoring of distant targets.
Bullet camera
Compact fixed-position camera for continuous monitoring of designated areas.
Flame detection camera
Specialized configuration incorporating flame detection technology for hazardous environments and fire safety monitoring.
Applications
- Offshore Oil & Gas Platforms
- LNG & LPG Carriers
- Tankers
- Cargo Vessels
- FPSO Facilities
- Marine Terminals
- Port Security Systems
- Offshore Wind Farms
- Refineries
- Chemical Processing Plants
- Vessel Navigation Support
- Berthing & Docking Operations
Features
- ATEX, IECEx, and KCs certified
- Suitable for Zone 1 and Zone 2 hazardous areas
- High-speed 380°/sec dome operation
- High-definition 2MP imaging system
- 20x optical zoom capability
- PTZ control for flexible monitoring
- Compact marine-grade housing
- IP68 environmental protection
- Designed for continuous operation
- Suitable for extreme weather conditions
- Reliable surveillance in hazardous environments
- Supports navigation and operational monitoring
Benefits
- Enhances maritime and offshore safety
- Improves situational awareness during navigation
- Provides rapid target acquisition and tracking
- Suitable for explosive and hazardous environments
- Delivers reliable operation in harsh marine conditions
- Supports vessel security and perimeter monitoring
- Reduces maintenance requirements through rugged construction
- Improves operational visibility in critical areas
- Enables continuous 24/7 monitoring
- Suitable for new installations and retrofit projects
Typical Installation Areas
- Bridge Wings
- Navigation Mast
- Cargo Deck Areas
- Offshore Platforms
- Loading Arms
- Jetty Facilities
- Helidecks
- Tank Farms
- Process Areas
- Pump Stations
- Security Perimeters
- Port Infrastructure
