Electric control air-actuated type remote manipulator CDQY-N
The CDQY-N Electric Control Air-Actuated Type Remote Manipulator from Guang Cai Electric is a remote valve operation solution designed for marine, industrial, and hazardous-area applications where safe and reliable valve actuation is required. The system combines electrical control with pneumatic actuation technology, enabling operators to remotely open, close, and monitor valves from a centralized control station.
Product description
Designed for demanding environments, the CDQY-N provides fast response, dependable operation, and reduced manual intervention during cargo handling, tank management, fluid transfer, and process control operations. The system enhances operational safety by allowing valves located in difficult-to-access or hazardous areas to be operated remotely while maintaining accurate position control and status indication.
The CDQY-N is a pneumatically actuated remote valve control device that utilizes electrical command signals to operate valves through an air-powered actuator mechanism. The system enables centralized valve operation from control rooms, local control panels, or integrated automation systems, improving operational efficiency and personnel safety.
Engineered for marine and industrial applications, the manipulator can be installed on ballast systems, fuel oil systems, cargo transfer systems, service tanks, process piping networks, and other fluid handling systems requiring remote operation.
Its robust construction and simple operating principle ensure reliable performance with minimal maintenance requirements. The system can also be integrated with monitoring and automation platforms for real-time valve status indication and operational feedback.
available configurations
| Configuration | Description |
|---|---|
| Local Control | Manual and local pneumatic operation |
| Remote Control | Electrical signal-based remote operation |
| Centralized Control | Integrated with vessel automation or control systems |
| Distributed Control | Installed across multiple valve locations with centralized monitoring |
Applications
- Ballast Water Systems
- Cargo Transfer Systems
- Fuel Oil Systems
- Service Tank Systems
- Engine Room Piping Networks
- Marine Process Control Systems
- Chemical Transfer Systems
- Offshore Platforms
- Industrial Fluid Handling Systems
- Utility and Process Pipelines
Key Features
- Electric control and pneumatic actuation
- Remote valve operation capability
- Fast response and reliable performance
- Suitable for hazardous and restricted locations
- Centralized control room operation
- Valve status monitoring support
- Low maintenance design
- Robust industrial construction
- Easy integration with automation systems
- Suitable for marine and industrial applications
Benefits
- Improves operator safety
- Reduces manual valve operation
- Enhances operational efficiency
- Enables centralized valve management
- Suitable for difficult-to-access valve locations
- Reliable operation in harsh environments
- Supports automation and process optimization
- Reduces operational downtime
| Parameter | Value |
|---|---|
| Product Type | Electric Control Air-Actuated Remote Manipulator |
| Model | CDQY-N |
| Control Method | Electrical Signal Control |
| Actuation Type | Pneumatic (Air Actuated) |
| Operation | Remote & Local Control |
| Application | Remote Valve Operation |
| Installation | Marine & Industrial Systems |
| Status Feedback | Optional Position Indication |
| Control Integration | PLC / SCADA Compatible |
| Construction | Industrial Duty Design |
| Maintenance Requirement | Low |
| Operating Environment | Marine, Offshore & Industrial Applications |
| Safety Function | Remote Isolation & Control Capability |
System functions
Remote valve operation
Allows operators to remotely open and close valves from a centralized control location without requiring physical access to the valve.
Pneumatic actuation
Utilizes compressed air to provide reliable and efficient valve movement, reducing mechanical effort and improving response times.
Automation integration
Can be connected to PLC, SCADA, and vessel automation systems for centralized monitoring and control.
Status monitoring
Supports valve position feedback and operational status indication to improve situational awareness and operational safety.
Typical Industries
- Marine & Shipbuilding
- Offshore Oil & Gas
- Tankers & Cargo Vessels
- Chemical Processing
- Power Generation
- Industrial Manufacturing
- Water Treatment Facilities
- Process Automation Systems
