Sole-Mate™
The Sole-Mate™ II is a footwear testing station used to verify the electrical resistance of static dissipative shoes before personnel enter hazardous areas. It measures the resistance loop through the operator and footwear to confirm that the shoes can safely dissipate electrostatic charge.
Description
The system provides a simple pass/fail indication and is commonly used at entry points to controlled industrial environments to support compliance with footwear testing requirements in hazardous locations.
Sole-mate™ ii footwear testing system
Application: Testing of static dissipative footwear before entry into hazardous areas
Function: Measures electrical resistance through footwear and operator body to verify static dissipation capability
Resistance Threshold Options
- EN ISO 20345: 1 × 10⁹ Ω
- IEC/TS 60079-32: 1 × 10⁸ Ω
- ASTM F2413: 1 × 10⁸ Ω
- CAN/CSA Z195-14: 1 × 10⁸ Ω
Status Indicators
- Green lamp: Pass (acceptable resistance level)
- Red lamp + buzzer: Fail (high resistance detected)
System Features
- Continuous footwear resistance testing via body loop measurement
- Entry control interlocking capability (doors/alarms optional integration)
- Compatible with hazardous area entry control systems
Power Supply
- Supplied with 6 ft cord and US 3-pin plug (US version)
- International version supplied with 3 m cable for wiring to mains supply
Maintenance
- Periodic tester verification recommended using resistance test unit
- Calibration check typically every 6–12 months depending on site procedures
Additional information
| Parameter | Value |
|---|---|
| Standard | "ISO 20345: "Footwear should normally have an electrical resistance of less than 1 x 109 ohms at all times during use. It is recommended that the user establish a test to check the electrical resistance of footwear and carry out checks at regular and frequent intervals."" |
| Certification | ATEX |
| Security level | Assets |
| Material | Polycarbonate |
| Application | Shoe testing |
| Zones installation | Safe zone |
| Material | Polyester housing / stainless steel base plate |
| Power supply | 240 Vac |
