IV8 Flameless Explosion Relief Vent
The IV8 Flameless Explosion Relief Vent is designed to protect process vessels located indoors or in areas where conventional explosion venting cannot be safely used. It provides pressure relief during an explosion while preventing flame discharge into the surrounding environment.
EquipmentFlameless Explosion Relief Vent
ManufacturerIEP Technologies
Type / Model / Part no IV8 Flameless Explosion Relief Vent
Description
During an explosion event, the vent opens and directs gases through a flame arresting mesh, which cools and quenches the flame before release. The system includes an integrated vent burst detection sensor to indicate activation and support operational response.
Technical specification
| Parameter | Value |
|---|---|
| Product Type | Flameless explosion relief vent |
| Venting Method | Pressure relief with flame arresting mesh |
| Maximum Protected Volume | Up to 49.2 m³ |
| Single Device Coverage | Up to 12.3 m³ |
| Dust Concentration Rating | Up to 1000 g/m³ |
| Certification | EN 16009 |
| Sensor | Integrated vent burst detection sensor |
| Frame Material | Carbon steel (coated) |
| Vent Material | Stainless steel |
Features
- Explosion pressure relief without flame ejection
- High-efficiency flame arresting mesh system
- Large mesh area for improved vent performance
- Unique folding mechanism for optimized venting efficiency
- Integrated vent burst detection sensor
- Multiple inspection ports for maintenance access
- Designed for field reconditioning
- Certified for use in high dust concentration environments (up to 1000 g/m³)
- Suitable for indoor explosion protection applications
