HP50-ION Power Unit
HP50-ION Power Unit is a high-voltage AC power supply designed to operate Fraser static eliminators with integrated Iontis performance monitoring. It provides controlled 6 kV ionising output with advanced operational feedback, safety protection, and remote monitoring capability for industrial static elimination systems.
EquipmentHigh Voltage Power Unit
ManufacturerFraser Anti-Static Techniques
Type / Model / Part noHP50-ION (3111)
Technical specification
| Parameter | Specification |
|---|---|
| Output Voltage | 6 kV AC |
| Maximum Peak Voltage | 7.75 kV |
| Secondary Current Limit | 5 mA |
| Maximum Load Capacity | 30 m combined bar and HT cable |
| Number of Outputs | Supports up to 4 static eliminators |
| Monitoring System | Integrated Iontis performance monitoring |
| Display Indicators | Power ON, HV OK, bar condition, cleaning status, fault alarm |
| Safety Protection | Automatic shutdown on overload or short circuit |
| Input Voltage | 115 V or 230 V AC |
| Input Frequency | 50 / 60 Hz |
| Power Consumption | Approx. 30 W |
| Power Connection | 2 m IEC power lead supplied |
| Construction | Powder-coated steel housing |
| Transformer Design | Fully encapsulated windings |
| Dimensions | 131.6 × 90.2 × 236.2 mm (W × H × L) |
| Mounting Width | 180 mm including bracket |
| Protection Rating | IP40 |
| Operating Temperature | Up to 50 °C |
| Up to 50 °C | Up to 70% RH non-condensing |
| Installation Environment | Dry and oil-free location |
| Compatible Equipment | Fraser AC static eliminators and EX-1250 |
| Remote Monitoring | Optional remote status monitoring |
| Certifications | CE, CB, UL |
