HP50-2 Power Unit
HP50-2 Power Unit is a compact high-voltage AC power supply designed to operate up to two Fraser static eliminators. It provides stable ionising power with integrated safety protection and reliable performance for industrial static elimination systems used on packaging and general manufacturing machinery.
EquipmentHigh Voltage Power Unit
ManufacturerFraser Anti-Static Techniques
Type / Model / Part noHP50-2
Technical specification
| Parameter | Specification |
|---|---|
| Output Voltage | 5.5 kV AC |
| Secondary Current Limit | 5 mA |
| Maximum Load Capacity | 12 m combined bar and HT cable |
| Supported Connections | Up to 2 static eliminators |
| Safety Protection | Automatic shutdown on overload or short circuit |
| Input Voltage | 115 V or 230 V AC |
| Input Frequency | 50 / 60 Hz |
| Power Consumption | Approx. 25 W |
| Power Connection | 2 m IEC lead supplied |
| Construction | Powder-coated steel housing |
| Transformer Design | Fully encapsulated windings |
| Dimensions | 123.4 × 89 × 168.7 mm (W × H × L) |
| Mounting Width | 168 mm including brackets |
| Protection Rating | IP40 |
| Operating Temperature | Up to 50 °C |
| Humidity | Up to 70% RH non-condensing |
| Installation Environment | Dry and oil-free location |
| Connection Type | Fraser HP connectors |
| Control Features | Local ON/OFF switch |
| Compatible Equipment | Fraser AC static eliminators |
| Certifications | CE, CB, UL |
