EVN Flameless Vent
The EVN Flameless Vent is designed for explosion protection in process vessels located indoors or in areas where standard explosion venting cannot be safely used. It combines a pressure relief vent with an integrated flame arrester that cools and extinguishes combustion gases during an explosion event, preventing flame release into the surrounding environment.
Description
During an explosion, the vent opens at low pressure and directs the explosion through the flame arresting element, which absorbs heat and suppresses flames. The system then reseals after discharge, helping reduce the risk of secondary fires or explosions.
Technical specification
| Parameter | Value |
|---|---|
| Product Type | Flameless explosion vent |
| Operating Principle | Pressure relief with integrated flame arresting element |
| Opening Pressure | 0.05 bar (standard) |
| Compliance | ATEX certified / NFPA compliant |
| Vacuum Resistance | Full vacuum resistant |
| Function | Internal explosion pressure relief without flame emission |
Features
- Internal explosion venting without external flame release
- Integrated flame arrester element
- Opens at low activation pressure (0.05 bar standard)
- ATEX certified and NFPA compliant
- Full vacuum resistance
- Immediate resealing after activation
- Suitable for indoor installation without vent ducts
- Available in multiple sizes and material configurations
