Earth-Rite® II MGV

Name: Earth-Rite® II MGV
Brand: Newson Gale
Availability: InStock

The Earth-Rite® MGV is a mobile truck-mounted static grounding system designed to confirm a valid ground connection during tanker truck transfer operations. It ensures that static electricity can be safely dissipated before and during loading or unloading of flammable products.

Static Grounding and Bounding Solutions

Earth Rite

EquipmentMobile Static Grounding System

ManufacturerNewson Gale

Type / Model / Part noEarth-Rite® MGV

Download PDF

Product description

The system uses tri-mode verification technology to confirm tanker recognition, validated grounding, and continuous low-resistance connection, ensuring safe process conditions throughout the transfer operation.

Earth-rite rtr™ basic specification

Specification	Details
Approvals & Certification	CSA US & Canada “Division Approval”: Cl I Div 1 Grps A-D; Cl II Div 1 Grps E,F,G; Cl III Div 1 CSA US “Zone Approval”: Class I, Zone 1, AEx d(ia) IIC T4; Class II, Zone 21, A21, IP66, T80C CSA Canada “Zone Approval”: Class I, Zone 1, Ex d(ia) IIC T4; DIP A21, IP66, T80C ATEX/IECEx: Ex d[ia] IIC T6 Gb(Ga), Ex tb IIIC T80C IP66 Db, Ta= -40C to +55C
Clamps	Body material: 304 stainless steel Contact points: two, tungsten carbide Body length: 9″/235mm
Cable	Hytrel coated spiral dual conductor cable, fitted with in-line quick-connect
Monitored Resistance	10 ohms upper limit
Status Indication	Red / green LED indication
Power Supply	AC powered version: 110/120V or 220/240V AC 50-60 Hz DC powered version: 12V or 24V DC
Output Relay	Contacts Two voltage-free change-over switch contacts, 250VAC, 5A, 500VA max. resistive load
Monitor	Weight 9.9 lbs / 4.5 Kg
Enclosure Materials	Monitor: copper-free cast aluminum Clamp Stowage Point: carbon loaded GRP
Ingress Protection	IP66 / NEMA 4X/7/9
Ambient Temperature	-13°F to +122°F / -40°C to +55°C
Options	Self-retracting cable reel. Ask about additional flashing beacons/strobes and alarm sounders

Earth-rite rtr™ available models

Model	Description
CSA version for US/Canada: Model RTRMUA1A3	Earth-Rite RTR™ Tri-Mode Static Grounding System, selectable 110/120 VAC or 220/240VAC, including heavy duty grounding clamp, 32 ft / 10m spiral cable and GRP clamp stowage point
ATEX & IECEx version: Model RTRMEA1A3A	Earth-Rite RTR™ Tri-Mode Static Grounding Unit – ATEX IIC, 220/240Vac ±10% including Heavy Duty grounding clamp, 10m retractable spiral cable, GRP clamp stowage box and operator instruction board.

Earth-rite rtr™ options

Model	Description
Model VESM02	Retractable Cable Reel with 50 ft / 15m of 2 conductor Hytrel protected static grounding cable
Model RTRT	Test Unit for RTR system installation, commissioning, and testing. Emulates typical tanker personality.
