Analyzer-Friendly Detector Tubes
Analyzer-Friendly Detector Tubes are specialized colorimetric gas sampling tubes designed for validated testing of impurities in ISBT beverage-grade CO₂. These tubes are used with compatible gas analyzers to provide accurate, direct-read measurements of trace contaminants. They are suitable for periodic batch testing as well as confirmatory or backup verification for continuous on-line monitoring systems. The range includes validated models from leading manufacturers and is supported by ISO/IEC 17025:2017 accredited laboratory methods.
AnalyzerFriendly Detector Tubes
ManufacturerGastec
Type / Model / Part noISBT Beverage Grade CO₂ Detector Tube Range
Technical specification
| Parameter | Value |
|---|---|
| Application | Detection of trace impurities in beverage-grade CO₂ and industrial gas streams |
| Standard Compliance | Validated for ISBT beverage grade CO₂ testing |
| Measurement Method | Colorimetric direct-read detector tube technology |
| Use Case | Batch testing, periodic verification, backup and confirmatory gas analysis |
| upport Laboratory Standard | ISO/IEC 17025:2017 accredited testing methods |
Compatible Analyzer Systems
- GAS-1P™ Single Channel Analyzer
- GAS-5XL™ Semi-Automatic Multi-Channel Analyzer
- SulfAlert-1™ Total Sulfur Analyzer (TSC capable)
Measured Gas Types & Tube Models
| Model | Description |
|---|---|
| Acetaldehyde | ALI 92AA (0.05–1.0 ppm) |
| Aromatic Hydrocarbon | ALI 121AHS (10–240 ppb) |
| Aromatic Hydrocarbon | ALI 121AHC (5–120 ppb) |
| Total Sulfur Content (TSC) | ALI 4TSC (0.025–0.2 ppm) |
| Sulfur Dioxide (SO₂) | ALI 103S02 (0.05–2.5 ppm) |
| Hydrogen Sulfide (H₂S) | ALI 4LT (0.025–0.2 ppm) |
| Nitrogen Dioxide (NO₂) | ALI 9NO2 (0.25–4 ppm) |
| Oxides of Nitrogen (NOx) | ALI 11NOx (0.25–6 ppm) |
| Carbon Monoxide (CO) | ALI 1CO (2.5–50 ppm) |
| Ammonia (NH₃) | ALI 105NH3 (0.25–5 ppm) |
| Methanol (MeOH) | ALI 111MOH (5–60 ppm) |
| Hydrogen Cyanide (HCN) | ALI 112HCN (0.2–10 ppm) |
| Vinyl Chloride (VCl) | ALI 131VCL (2–60 ppb) |
| Phosphine | ALI 7LA (0.1–1.5 ppm) |
| Water Vapor (H₂O) | ALI 6H2O (2.5–50 ppm) |
Find the Right Tube
Search By
| Chemical | Range | Part No. | Qty/Box | Type | Actions | |
|---|---|---|---|---|---|---|
| Acetaldehyde | 5-750 | 92 | 10 | Short-term measurement | Inquire | Download |
| Acetaldehyde | 2.5-100 | 92M | 10 | Short-term measurement | Inquire | Download |
| Acetaldehyde | 1-20 | 92L | 10 | Short-term measurement | Inquire | Download |
| Acetaldehyde | 0.3-30 | 92LA | 10 | Short-term measurement | Inquire | Download |
| Acetone | 4-1200 | 151D | 10 | Long-term measurement | Inquire | Download |
| Methyl ethyl ketone | 1.2-360 | 152D | 10 | Long-term measurement | Inquire | Download |
| Formaldehyde | 0.1-20 | 91D | 10 | Long-term measurement | Inquire | Download |
| Acetic acid | 1-100 | 81 | 10 | Short-term measurement | Inquire | Download |
| Acetic acid | 0.125-23.0 | 81L | 10 | Short-term measurement | Inquire | Download |
| Acetic acid | 0.5-100 | 81D | 10 | Long-term measurement | Inquire | Download |
...
