740 Surface Resisitance Meter

Name: 740 Surface Resisitance Meter
Brand: Fraser Anti-Static Techniques
Availability: InStock

The 740 Surface Resistance Meter is a compact handheld instrument designed for measuring the surface resistance of conductive, static dissipative, and insulative materials. It provides fast and repeatable measurements using the ASTM standard parallel bar sensing method and is commonly used for testing electronics packaging materials, work surfaces, and other applications where electrical surface properties are critical.

Static Neutralization and Generations

Static Mesurement

Equipment Surface Resistance Meter

ManufacturerFraser Anti-Static Techniques

Type / Model / Part no 740 Surface Resistance Meter

Download PDF

Technical specification

Specification item	Details
Equipment type	Surface resistance meter
Application	Measurement of conductive, static dissipative, and insulative surfaces
Measurement range	10³ to 10¹²+ Ohms/Square
Measurement method	ASTM standard parallel bar sensing
Resolution	One order of magnitude
Changeover point	½ decade on logarithmic scale (3.15 × 10ⁿ)
Accuracy	±10%
Repeatability	±5%
Construction	Pocket-sized handheld instrument
Dimensions	70 × 130 × 35 mm
Weight	103 g
Battery type	9 V PP3 alkaline
Test operation	LED indication for resistance decade values
Included accessories	Carrying case, battery, earth lead
Environmental limits	5–50 °C, 0–90% RH non-condensing
Certification	CE
