4125 Ionised Air Gun

Name: 4125 Ionised Air Gun
Brand: Fraser Anti-Static Techniques
Availability: InStock

4125 Ionised Air Gun is a high-performance industrial cleaning and static elimination device designed for removing dust, contaminants, and electrostatic charges from components and surfaces. It combines powerful ionisation with amplified compressed air flow to provide efficient cleaning performance with low air consumption and shockless operation.

Static Neutralization and Generations

Static Elimnation

EquipmentIonised Air Gun

ManufacturerFraser Anti-Static Techniques

Type / Model / Part no4125

Download PDF

Technical specification

Parameter	Value
Ionisation Voltage	5.5 – 6 kV
Ionisation Type	External AC ionisation
Air Amplification Ratio	20:1
Maximum Air Pressure	10 Bar
Typical Working Pressure	5 Bar
Air Consumption	560 l/min at 5 Bar
Air Connection	1/4” BSP threaded connection
Air Fitting	8 mm OD push-fit fitting
Recommended Supply Pipe	Minimum 6 mm ID
Thrust Performance	5.2 N at 100 mm distance and 5 Bar
Construction	Stainless steel, PTFE, aluminium, plastic
Ionisation Head Material	Stainless steel and PTFE
Nozzle Material	Aluminium
Cable Type	Hi-Flex HT cable
Standard Cable Lengths	3 m, 5 m, 7 m, 10 m
3 m, 5 m, 7 m, 10 m	Fraser 5.5 kV and 6 kV Power Units
Safety Features	Shockless operation, OSHA compliant
Noise Level	74 dBA at 5 Bar
Air Requirement	Clean and dry compressed air
Cleanroom Compatibility	ISO Class 6
Robot Cable Test Standard	9560 ETE 014800
Installation Options	Top or bottom air feed
Certification	CE

Features

Ergonomic full-hand trigger for reduced operator fatigue
Modular design with replaceable parts for easy maintenance
High thrust cleaning performance with low air consumption
Suitable for mouldings, graphics, lenses, assemblies, mirrors, and automotive components
Supports operation with one to four guns from a Fraser HP Power Unit
